Specifications and performance data

Specifications and performance data

Dimensions:

Title Value
Wing span 10.90 m
Length 15.30 m
Height 5.30 m

Weight:

Title Value
Overall empty weight 10 t (22,000 lbs) class
Max. take-off weight 24.5 t (54,000 lbs)
Fuel (internal) 4.7 t (10,300 lbs)
Fuel (external) up to 6.7 t (14,700 lbs)
External load 9.5 t (21,000 lbs)

Store stations:

Title Value
Total 14
Heavy-wet 5

Performances

Title Value
Max. thrust 2 x 7.5 t
Limit load factors -3.2 g / +9 g
Max. speed M = 1.8 / 750 knots
Approach speed less than 120 knots
Landing ground run 450 m (1,500 ft) without drag-chute
Service ceiling 50,000 ft
